GFS-200 Solar Street Light

GFS-200 Solar Street Light

20FT CYCLONE RATED DESIGN

Description

As towns and cities continue to develop at a fast pace, there’s growing need for lighting in streets and public spaces to create a feeling of safety. The GFS-200 allows you to quickly and easily install powerful scale-able lighting solutions with zero running costs compared with main supply. Advanced reliable technology that directly addresses the growing demands on your infrastructure.

Technical Information

KEY FEATURES
  • Unrivaled CREE LED Technology
  • Sophisticated Mono Crystalline Solar Panel
  • Complete Unit IP-65 Protected
  • Cyclone/Hurricane/Typhoon Weather Rating
  • Advanced LED Compensation Technology
  • Intelligent Battery Management System (IBMS)
  • Durable Construction & Quality Components
  • Pole Integrated Battery Pack
    • KEY BENEFITS
  • Power to Run All Night
  • No External Cabling or Trenching Required.
  • Install Without Electrician
  • Extreme Weather Resistance
  • Impact Resistant & Vandal Proof
  • Safe Consistent Performance & Lifespan
  • Ultra Reliable Built to Last
  • Zero Maintenance System
  • Warranty Included
  • Fully Customer Endorsed
  • Smart City Ready
    • PERFORMANCE
  • Designed to give all night operation up to 14 hours per night in all weather conditions at 5,610 Lumens
    • MOUNTING HEIGHT
  • Maximum Height = 30 Ft.
  • Suggested Height = 23 Ft.
    • TECHNICAL INFORMATION

    LED

  • 28 x USA made CREE XP-G led configured in 2 x 14 LED arrangement
  • 5,610 lumens total output
  • 4000K CCT, 70 CRI 187lm/w
  • Dual LED Module for ultimate reliability
  • Constant LED power output ensures consistent output all night

    • LENS

  • Sophisticated, indestructible polycarbonate lens allows for precise evenly distributed directional illumination output. Dual Lens design provide flexibility in lens mixing. (type 3 / 5)
  • Meets International lighting standards, less poles required for significantly more illumination
  • Dual Lens – Type 3 pathway / roadway 135º85º (standard)
  • Mix Lens – Type 3 & 5 lens 110º + 135 (optional)

    • POLE + FRAME

  • 85 micron zinc coating for complete corrosion resistance
  • 0.12″ – 0.63″ Galvanized Steel

    • SOLAR PANEL

  • High Grade – 21% class leading efficiency, sophisticated technology making it highly sensitive and more efficient than standard panels on the market.
  • Impact resistance, solar panel equipped with back panel stone guard
  • Anti bird spike
  • 360D adjustable solar panel facing, flexible installation and maximize solar power output

    • BATTERY

  • Flood proof deep cycle sealed gel battery
  • 2 x 12V 2x75Ah (1800wh)
  • 60 hours continuous light output in all night mode
  • 5 days backup power**

    • SMART CONTROLLER

  • Monitors all vitals of the unit, including LED, Solar, battery, temperature
  • Built-in soft start constant current LED driver with over voltage, over current, short circuit protection
  • Tri-Color Controller status indicator LED
  • Intelligent multistage charge profile
  • MPPT Charging with 99% tracking efficiency
  • IOT Ready smart city***
  • Flexible on /off programs
  • Auto /On /OFF set as default (on at dusk, off at dawn)
  • Ability to program turn on hours, before sunrise
  • RS485 interface with hand programmer

    • HOUSING & PAINT

  • Hot dip galvanized for complete corrosion resistance, built to last for ultra reliability.

    • OPERATING TEMPERATURE

  • -4ºF to 140ºF (-20ºC to 60ºC)

    • SAIL AREA

  • 5.78 ft square

    • WARRANTY

  • 5 year warranty*****

    • CERTIFICATIONS

  • Product and component certifications listed UL E349212 LED, UL3135 Cabling, UL1598 Safety Luminaires, UL8750 LED Safety Certified to meet ANSI/IES RP-8-14 and ANSI/IES RP-20-14 lighting standards”

    • ****Days backup is calculated on a 12 hour night time operation @ 5610 lumens
    ******when fitted with optional control system
    ********GFS does NOT guarantee lighting performance due to many factors outside of GFS control such as shading, dirt, bird fouling and excessive triggering, however based on test data from numerous installs across the world 14 hour a night operation has been achieved in typical installs
    ********** 5 year on all components except battery (3 year) refer to specific warranty T&C’s document
